Special Application Leveler with Custom Engineering

1 / 5

Special Application Leveler with Custom Engineering

Application:	Workshop Crane, Shipboard Crane, Warehouse Crane, Building Crane
Lift Mechanism:	Scissor Lift
Carrying Capacity:	Weight Level

Send Inquiry

Product Description

Basic Information

Model NO.:

DL141

Product Name:

Dock Leveler

Driven Type:

Hydraulic

Running Mode:

Stationary

Rated Load:

Net Load 8 Tons, Dynamic Load 6 Tons

Dimensions:

2000mm W x 2500mm L x 600mm H

Power Form:

Electric-Hydraulic

Adjustment Range:

+300/-300m

Certification:

GS, CE, RoHS, ISO 9001

Features:

Explosion-Proof, Insulating

Product Description

DOCK LEVELER

Loading and unloading platforms are suitable for hydraulic, pneumatic, or mechanical installations. It helps users safely and efficiently unload trucks of all heights and sizes. The primary function is to build a bridge between the cargo platform and the transport vehicle, allowing the forklift to travel conveniently for unloading.

It can automatically adjust its height according to different vehicle models and changes in the vehicle compartment during loading. This product is specifically designed to meet diverse operational needs regarding dimensions and load-bearing capacity.

Detailed Photos & Key Features

⚡ All-Weather Operational

Featuring a high-traction, anti-slip surface and weather-resistant components, our Dock Leveler guarantees reliable performance in wet, icy, or challenging conditions.

⚙️ Tailored Solutions

Get a perfect fit for your facility's specific needs. We offer customizable options for size, capacity, and control systems to ensure seamless integration.

🌱 Energy-Smart Performer

Advanced hydraulic systems engineered for low energy consumption without sacrificing power or speed, benefiting both workflow and utility costs.

Technical Parameters

Technical Specifications
Rated Load	Net Load 8 Tons, Dynamic Load 6 Tons
Equipment Dimensions	2000mm Wide, 2500mm Long, 600mm High
Pit Size	Width: 2030mm, Length: 2500mm, Height: 610mm
Adjustment Range	+300/-300mm
Adjust Time	Up Time ≤ 16s, Down Time ≤ 10s
Board Thickness	12mm Plate, 400mm Length
Main Console Panel	6mm Patterned Board
Hydraulic Oil	32# Anti-Wear Hydraulic Oil
Working Pressure	8MPa +/- 1MPa
Base Frame	10# Channel Steel Welded H-Shaped Structure
Safety Features	Automatically Retractable Side Baffles

Operational Advantages

🏗️ Superior Durability

Constructed with high-strength, industrial-grade steel to withstand heavy loads and continuous use in demanding environments.

🛡️ Enhanced Safety

Equipped with full-range toe guards and velocity fuses to protect workers and equipment, reducing the risk of accidents.

🚀 Improved Productivity

Speeds up loading cycles by providing a stable and efficient platform, boosting overall operational throughput.

Application & Installation

Frequently Asked Questions

Q1: Are you a manufacturer or a trading entity? A: We are a manufacturer integrating industry and trade, providing comprehensive solutions for loading dock equipment.

Q2: Can the dock leveler be customized with specific logos or colors? A: Yes, we support full on-demand customization, including LOGO placement, color selection, and specific size adjustments.

Q3: What safety features are included in your dock levelers? A: Our units come equipped with automatically retractable side body guard baffles, velocity fuses, and high-traction surfaces to ensure maximum safety.

Q4: How do I determine the correct pit size for installation? A: Standard pit dimensions for our DL141 model are 2030mm Width, 2500mm Length, and 610mm Height, but we can provide specific guidance based on your site requirements.

Q5: What payment methods and shipping options are available? A: We support T/T, Western Union, and PayPal. Transportation is typically handled via sea, air, or land depending on the destination and cargo conditions.

Q6: How can I receive a detailed quotation for a project? A: Please provide your specific load requirements and site dimensions. We will customize a technical solution and provide an accurate price breakdown.
