Standard Twelve Feet Wide Dock Leveler for Accommodating Wider Loading Needs

1 / 5

Standard Twelve Feet Wide Dock Leveler for Accommodating Wider Loading Needs

Application:	Workshop Crane, Shipboard Crane, Warehouse Crane, Building Crane
Lift Mechanism:	Scissor Lift
Carrying Capacity:	Weight Level

Send Inquiry

Product Description

Basic Specifications

Model NO.	DL331	Moves	Stationary
Driven Type	Hydraulic	Running Mode	Stationary
Feature	Explosion-Proof, Insulating	Certification	GS, CE, RoHS, ISO 9001
Rated Load	Net 8 Tons, Dynamic 6 Tons	Equipment Dimensions	2000mm W x 2500mm L x 600mm H
Power Form	Electric-Hydraulic	Adjustment Range	+300/-300mm
Production Capacity	500,000 Pieces/Year	Origin	China

★

Product Description

High-Performance Dock Leveler

Loading and unloading platforms are essential for hydraulic, pneumatic, or mechanical installations. This equipment helps users safely and efficiently manage trucks of all heights and sizes.

Our solutions bridge the gap between the cargo platform and the transport vehicle, facilitating convenient forklift travel for unloading. It automatically adjusts its height according to different vehicle models and weight changes during operation.

Detailed Features

All-Weather Continuity

Featuring a high-traction, anti-slip surface and weather-resistant components for reliable performance in wet or icy conditions.

Tailored Infrastructure

Fully customizable solutions including size, capacity, and control systems to fit your specific architectural requirements.

Energy-Smart Performer

Advanced hydraulic systems engineered for low energy consumption without sacrificing power or speed.

Technical Parameters

Parameter Item	Detailed Specification
Pit Size Required	Width: 2030mm, Length: 2500mm, Height: 610mm
Adjustment Time	Up Time ≤ 16s \| Down Time ≤ 10s
Board Thickness	12mm / 400mm length
Main Console Panel	6mm Patterned Board
Motherboard Skeleton	L-Shaped Bend
Safety Features	Automatically Retractable Side Body Guard Baffles
Hydraulic Pressure	8MPa +/-1MPa (32# Anti-Wear Oil)
Base Frame	10# Channel Steel Welded H-Shaped Structure
Operational Life	≥ 200,000 Cycles

Effortless Integration: Designed to bridge the gap between dock and varying truck heights seamlessly.

Superior Durability: High-strength, industrial-grade steel construction for continuous heavy-load use.

Enhanced Safety: Equipped with full-range toe guards and velocity fuses to reduce accident risks.

Productivity Boost: Faster loading cycles boost overall operational throughput and efficiency.

Frequently Asked Questions

What is the primary function of this Dock Leveler?

It acts as a bridge between your loading platform and transport vehicles, allowing forklifts to transition safely and efficiently despite differences in height.

Does the equipment support customization?

Yes, we support on-demand customization including color, dimensions, load capacity, and control systems to meet specific operational needs.

What safety mechanisms are included?

The unit includes automatically retractable side body guard baffles, full-range toe guards, and a velocity fuse to protect both personnel and equipment.

How does the automatic height adjustment work?

The electric-hydraulic system adjusts the platform height automatically in response to the vehicle's movement and weight fluctuations during loading and unloading.

What are the power and pressure requirements?

It operates on an electric-hydraulic system with a working pressure of 8MPa +/-1MPa, utilizing 32# anti-wear hydraulic oil.

Is the platform durable for high-frequency use?

Absolutely. It is constructed from 10# channel steel and 6mm patterned board, designed for a lifespan of at least 200,000 cycles.
